Industrial high shear emulsifier mixer is a mixing equipment with excellent performance developed by our company integrating international and domestic advanced technology. Mixing tank with agitator is widely used in viscous and liquid products in cosmetics, food, pharmaceutical, biological, chemical and other industries.
This mixing equipment is made of corrosion-resistant stainless steel, which can meet the multiple processing demand of products.
* Mixing Type: the mixer can be designed as per processing request, such as frame mixing paddle, helical ribbon mixer, anchor agitator, wall scraping mixing paddle, high-speed dispersing plate and other different styles of paddles;
* Heating type: electric heating, steam heating and other heating forms can be option;
* Mixing power: stirring motors with different powers such as 1.1KW, 2.2KW, 3KW, 4KW, 5.5KW can be selected;
* According to the effect of dissolving and mixing, homogeneous motors with different powers such as 1.1KW, 2.2KW, 3KW, 4KW and 5.5KW can be selected.
With many years of experience in mixing equipment manufacturing, we supplied plenty of mixing tanks over the world. Focusing on customers, it is the unremitting pursuit of every Immay person to develop mixing equipment that meets customer process requirements.
We sincerely look forward to becoming your excellent partner and helping you achieve success.
Usage
The mixing tank is available for manufacturing liquid products(such as detergent, shampoo, shower gel, etc.) , it integrates mixing, homogenizing, heating, cooling, pump discharging finished products functions.
Performances and Features
1. The omni-directional wall scraping mixing system of the mixing tank ensures the full integration of materials.
2. The mixing tank can be equipped with homogenizer and heating system to meet the different production process requirements of customers.
3. The tank body of the mixing tank is rolled and welded with high-quality stainless steel plate.
4. The main body and pipeline of the mixing tank are polished to meet the GMP requirements.
5. The mixing tank uses the core components of famous brands for excellent performance.
Working Capacity | Mixing | Homogenizer | Dimension (mm) | Heating way | |||||
Power | Speed | Power | Speed | Length (mm) | Width(mm) | Height (mm) | Electric heating | Steam heating | |
200L | 1.5~2.2 | 0~63 | 2.2~4 | 0~3000 | 1800 | 1600 | 1800 | 12KW | 5 |
300L | 2.2~3 | 0~63 | 3~4 | 0~3000 | 2000 | 1700 | 2000 | 15KW | 5 |
500L | 3~4 | 0~63 | 4~5.5 | 0~3000 | 2200 | 2200 | 2350 | 18KW | 9 |
1000L | 4~5.5 | 0~63 | 5.5~7.5 | 0~3000 | 2500 | 3000 | 2800 | 36KW | 13 |
1500L | 4~5.5 | 0~63 | 7.5~11 | 0~3000 | 2650 | 3100 | 3300 | 36KW | 13 |
2000L | 7.5~11 | 0~63 | 11~15 | 0~3000 | 2900 | 3500 | 3550 | 48KW | 15 |
3000L | 11~15 | 0~63 | 15~18 | 0~3000 | 3100 | 3800 | 3800 | 72KW | 30 |
5000L | 11~15 | 0~63 | 18~22 | 0~3000 | 3500 | 4000 | 4200 | 96KW | 40 |
Recommended Product
Quality & Project
Q: Which information shall I offer before getting solution?
A: Which product will you produce?
B: How many liter per batch or per day do you request ?
C: Are there other more requests?
Q:Which machine should I choose?
A:It depends on product you make and the formula process, we will offer you tailor-made design.
Q: I am working on a new processing line that don't know much about what I need, how can you support?
A: We have supplied production line equipments to thousands clients in diverse industries within our decade experience, we will tailor-made you equipments that with fit your capacity request and optimize product performance.
Q:How can you control the quality and delivery?
A:Production strictly according to CE / ISO standards.
B:All our machines will be tested before packaging. Wooden packaing is safe during shipping.
Q: How long is your delivery time?
A: Generally it is 15-30 days, depends on production schedule.
Born in Yangzhou, China, Immay is a leading enterprise specializing in R&D, production and sales of equipment in cosmetics, pharmaceutical, food and beverage, daily health products, chemical and other industries.
As a leading manufacturer of cream and liquid processing equipment, we have developed a variety of machines, including reverse osmosis water treatment equipment, vacuum homogenizer mixer, mixing tank, storage tank, filling machine, capping machine, packaging machine and labeling machine..
The spirit of "dedication and excellence" is deeply rooted in the corporate culture of Immay. We focus on professional and meticulous processes and regard quality as soul of our company.
We keep pace with times, explore and innovate, keep up with the pace of industrial intelligent manufacturing, continue to promote technological innovation, continue to research and develop more advanced and better products, and strive to support customers to improve production capacity and increase profits through more efficient and intelligent equipment.
