Vacuum Mixing Machine for Cream Ointment Paste Liquid Production

Share to:

Vacuum Mixing Machine for Cream Ointment Paste Liquid Production

Availability:



Inquire Add to Basket

Product Description

Vacuum Homogenizer Emulsifier Mixer and Reactor is a high-quality product developed by our company in combination with international and domestic advanced technology. It is suitable for the production of viscous materials such as foundation, toothpaste, cream and so on. Its outstanding feature is that under the dual action of the homogenizer and the stirring paddle, the material can be well fused, so that the material can be completely emulsified.

vacuum mixing machine

Performances and Features

1. Vacuum homogenizer emulsifier is professionally designed for cream/paste producing, with advanced homogenizing technology.

2. Vacuum homogenizer mixer is composed of water tank, oil tank, vacuum emulsifying tank, vacuum pump, hydraulic system, discharge system, electric control system and working platform etc.

3. The vacuum mixer homogenizer lifting systems include single-cylinder lifting and double-cylinder lifting. Various high quality products can be customized according to customers’ requirements.

4. The vacuum mixer adopts famous brand frequency converter for speed adjustment, which can meet different technological demands.

5. The vacuum defoaming makes materials up to aseptic request.

Model	Effective Capacity	Homogenizer		Mixing		Dimension (mm)			Heating(KW)		Limited Vacuum (Mpa)
Model	Effective Capacity	Power (KW)	Speed (RPM)	Power (KW)	Speed (RPM)	Length (mm)	Width (mm)	Height (mm)	Electric heating	Steam heating	Limited Vacuum (Mpa)
IMA-5S1B	5L	0.37	0~3000	0.18	0~63	1260	540	1600/1850	5	2	-0.09
IMA-10S1B	10L	0.55~0.75	0~3000	0.37~0.55	0~63	1300	580	1600/1950	6	3	-0.09
IMA-30S1B	30L	1.1~2.2	0~3000	0.55~0.75	0~63	1800	1000	1750/2300	18	9	-0.09
IMA-50S1B	50L	2.2~3	0~3000	0.75~1.1	0~63	2430	1230	1850/2600	18	9	-0.09
IMA-100S1B	100L	3~5.5	0~3000	1.1~1.5	0~63	2800	1500	2000/2750	32	13	-0.09
IMA-200S1B	200L	4~7.5	0~3000	1.5~2.2	0~63	2800	1850	2300/3300	45	15	-0.09
IMA-300S1B	300L	5.5~7.5	0~3000	2.2~3	0~63	3000	1950	2400/3450	45	18	-0.085
IMA-500S1B	500	7.5~11	0~3000	3~4	0~63	3300	2100	2750/3900	50	27	-0.08
IMA-1000S1B	1000	11~15	0~3000	5.5~7.5	0~63	4200	3600	3250/4800	85	30	-0.08
